ADA4932-1/ADA4932-2
Rev. 0 | Page 17 of 28
TEST CIRCUITS
ADA4932-x
1k
Ω
+5V
–5V
499
Ω
499
Ω
50
Ω
DC-COUPLED
GENERATOR
499
Ω
0.1µF
499
Ω
VOCM
53.6
Ω
25.5
Ω
VIN
Figure 52. Equivalent Basic Test Circuit, G = 1
ADA4932-x
+5V
0.1µF
–5V
499
Ω
499
Ω
50
Ω
499
Ω
NETWORK
ANALYZER
INPUT
NETWORK
ANALYZER
INPUT
NETWORK
ANALYZER
OUTPUT
AC-COUPLED
50
Ω
50
Ω
499
Ω
49.9
Ω
49.9
Ω
VOCM
53.6
Ω
VIN
Figure 53. Test Circuit for Output Balance, CMRR
ADA4932-x
+5V
–5V
499
Ω
499
Ω
50
Ω
499
Ω
442
Ω
442
Ω
0.1µF
499
Ω
VOCM
53.6
Ω
261
Ω
200
Ω
HP
LP
2:1
50
Ω
CT
VIN
LOW-PASS
FILTER
DC-COUPLED
GENERATOR
0.1µF
0.1µF
DUAL
FILTER
25.5
Ω
Figure 54. Test Circuit for Distortion Measurements
