VIPer12ADIP / VIPer12AS

3/15

ABSOLUTE MAXIMUM RATINGS

THERMAL DATA

Note: 1. When mounted on a standard single-sided FR4 board with 200 mm² of Cu (at least 35

µm thick) connected to all DRAIN pins.

POWER SECTION

Note: 1. On clamped inductive load

Symbol

Parameter

Value

Unit

(See note 1)

-0.3 ... 730

V

(See note 2)

-0.3 ... 400

V

Continuous Drain Current

Internally limited

A

Supply Voltage

0 ... 50

V

Feedback Current

3

mA

Electrostatic Discharge:

Machine Model (R=0

Ω; C=200pF)

Charged Device Model

200

1.5

V

kV

Junction Operating Temperature

Internally limited

°C

Case Operating Temperature

-40 to 150

°C

Storage Temperature

-55 to 150

°C

Symbol

Parameter

Max Value

Unit

Rthj-case

Thermal Resistance Junction-Pins for:

SO-8

DIP8

25

15

°C/W

Rthj-amb

Thermal Resistance Junction-Ambient for:

SO-8

(See note 1)

DIP8

(See note 1)

55

45

°C/W

Symbol

Parameter

Test Conditions

Min.

Typ.

Max.

Unit

Drain-Source Voltage

730

V

Off State Drain Current

0.1

mA

Static Drain-Source

On State Resistance

27

30

54

Ω

Fall Time

(See fig.1)

(See note 1)

100

ns

Rise Time

(See fig.1)

(See note 1)

50

ns

Drain Capacitance

40

pF
