background image
INCHANGE Semiconductor
isc Product Specification
isc Website：www.iscsemi.cn
isc Silicon PNP Power Transistor
2SA982
ELECTRICAL CHARACTERISTICS
Tj=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC= -50mA ;IB= 0
-140
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= -3A; IB= -0.3A
-1.5
V
ICBO
Collector Cutoff Current
VCB= -140V; IE= 0
-1.0
mA
IEBO
Emitter Cutoff Current
VEB= -6V; IC= 0
-1.0
mA
hFE
DC Current Gain
IC= -3A; VCE= -4V
30
fT
Current-Gain—Bandwidth Product
IE= 0.5A; VCE= -12V
20
MHz
Switching times
tr
Rise Time
0.85
μs
tstg
Storage Time
2.0
μs
tf
Fall Time
IC= -3A ,RL= 4Ω, VCC= -12V
IB1= -0.2A; IB2= 0.1A
0.3
μs
