LTC2053/LTC2053-SYNC

2053syncfb

Gain Error

AV = 1

●

0.001

0.01

Gain Nonlinearity

AV = 1

●

ppm

Input Offset Voltage (Note 2)

VCM = 0V

±20

µV

Average Input Offset Drift (Note 2)

TA = – 40°C to 85°C

●

±50

nV/°C

TA = 85°C to 125°C

●

–1

–2.5

µV/°C

Average Input Bias Current (Note 3)

VCM = 1V

●

410

Average Input Offset Current (Note 3)

VCM = 1V

●

Common Mode Rejection Ratio

AV = 1, VCM = – 5V to 5V, LTC2053C

●

105

118

(Notes 4, 5)

AV = 1, VCM = – 5V to 5V, LTC2053C-SYNC

●

100

118

(Notes 4, 5)

AV = 1, VCM = – 4.9V to 4.9V, LTC2053I

●

105

118

AV = 1, VCM = – 4.9V to 4.9V, LTC2053I-SYNC

●

100

118

AV = 1, VCM = – 5V to 5V, LTC2053I, LTC2053I-SYNC

●

118

AV = 1, VCM = –4.9V to 4.9V, LTC2053H

●

100

AV = 1, VCM = –5V to 5V, LTC2053H

●

Power Supply Rejection Ratio (Note 6)

VS = 2.7V to 11V

●

110

116

Maximum Output Voltage Swing

RL = 2k to GND, C and I Grades

●

±4.5

±4.8

RL = 10k to GND, All Grades

●

±4.6

±4.9

RL = 2k to GND, LTC2053H Only

●

±4.4

±4.8

Supply Current

No Load

●

0.95

1.3

Supply Current, Shutdown

VEN ≥ 4.5V, LTC2053 Only

µA

EN Pin Input Low Voltage, VIL

– 4.5

CLK Pin Input Low Voltage, VIL

0.5

EN/CLK Pin Input High Voltage, VIH

4.5

EN/CLK Pin Input Current

VEN/CLK = V–

–3

– 20

µA

Internal Op Amp Gain Bandwidth

200

kHz

Slew Rate

0.2

V/µs

Internal Sampling Frequency

3kHz

Note 1: Absolute Maximum Ratings are those values beyond which the life

of a device may be impaired.

Note 2: These parameters are guaranteed by design. Thermocouple effects

preclude measurement of these voltage levels in high speed automatic test

systems. VOS is measured to a limit determined by test equipment

capability.

Note 3: If the total source resistance is less than 10k, no DC errors result

from the input bias currents or the mismatch of the input bias currents or

the mismatch of the resistances connected to –IN and +IN.

Note 4: The CMRR with a voltage gain, AV, larger than 10 is 120dB (typ).

Note 5: At temperatures above 70°C, the common mode rejection ratio

lowers when the common mode input voltage is within 100mV of the

supply rails.

Note 6: The power supply rejection ratio (PSRR) measurement accuracy

depends on the proximity of the power supply bypass capacitor to the

device under test. Because of this, the PSRR is 100% tested to relaxed

limits at final test. However, their values are guaranteed by design to meet

the data sheet limits.

The

● denotes the specifications which apply over the full operating

temperature range, otherwise specifications are at TA = 25°C. V+ = 5V, V– = – 5V, REF = 0V.

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

ELECTRICAL CHARACTERISTICS
