HFC

high frequency ceramic capacitor

applications and ratings (continued)

environmental applications

100

1

Capacitance

(pF)

1

0.1

10

10

HFC1410, 1608, 1610, 1612 Series

10000

1

Frequency

(MHz)

1000

500

1800

100

10

1000

Type: HFC1612VT1R0R05M50 (1.0 PF)

Q vs. Frequency

Self Resonant Frequency (SRF)

vs. Capacitance Value

ESR vs. Frequency

5

0.01

Frequency

(MHz)

1000

500

1800

1

0.1

±0.075

±0.015

±0.030

V

C

T

N

50

-55°C to +125°C

50

-55°C to +125°C

Part

Designation

Tolerance Code

(pF)

Material

Code

Operating

Temperature

Range

Rated

Voltage

DC (V)

Capacitance

(pF)

HFC1410VTTE1R1

1.10

HFC1410VTTE1R2

1.20

HFC1410VTTE1R3

1.30

HFC1608CTTER10

0.10

HFC1608TTTER15

0.15

HFC1608NTTER20

0.20

HFC1608NTTER25

0.25

HFC1608NTTER30

0.30

HFC1608NTTER35

0.35

±0.030

V

V

V

50

-55°C to +125°C

HFC1608VTTER40

0.40

HFC1608VTTER45

0.45

HFC1608VTTER50

0.50

HFC1608VTTER55

0.55

HFC1610VTTER60

0.60

HFC1610VTTER65

0.65

HFC1610VTTER70

0.70

HFC1610VTTER75

0.75

HFC1610VTTER80

0.80

HFC1610VTTER85

0.85

HFC1610VTTER90

0.90

HFC1612VTTER95

0.95

HFC1612VTTE1R0

1.00

±0.050

±0.050

50

-55°C to +125°C

259

KOA Speer Electronics, Inc. • Bolivar Drive • P.O. Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com

Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.

3/10/07
