background image
Inchange Semiconductor
Product Specification
2
Silicon NPN Power Transistors
2SC4589
CHARACTERISTICS
Tj=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR )CEO
Collector-emitter breakdown voltage
IC=10mA; RBE=∞
800
V
V(BR )EBO
Emitter-base breakdown voltage
IE=10mA; IC=0
5
V
VCE(sat)
Collector-emitter saturation voltage
IC=8A; IB=1.6 A
5.0
V
VBE(sat)
Base-emitter saturation voltage
IC=8A; IB=1.6 A
1.5
V
ICES
Collector cut-off current
VCE=1500V;RBE=0
500
μA
IEBO
Emitter cut-off current
VEB=5V; IC=0
100
μA
hFE
DC current gain
IC=1A ; VCE=5V
8
38
tf
Fall time
ICP=7A; IB1=1.4A
0.2
0.5
μs
