Ordering Information

Part No.

Description

LENS-B

Wall mount lens attachment, blue

LENS-R

Wall mount lens attachment, red

LENS-G

Wall mount lens attachment, green

LENS-A

Wall mount lens attachment, amber

LENS-BC

Ceilingmountlensattachment,blue

LENS-RC

Ceilingmountlensattachment,red

LENS-GC

Ceilingmountlensattachment,green

LENS-AC

Ceilingmountlensattachment,amber

ColorlensattachmentsmaybeusedwiththefollowingSystemSensor

non-fire (Plain) indoor or outdoor strobe models: SR-P, SRH-P, SW-P, SWH-P,

P2R-P, P2RH-P, P2W-P, P2WH-P, P4R-P, P4RH-P, P4W-P, P4WH-P, P2RK-P, P2RHK-P,

SCR-P,SCRH-P,SCW-P,SCWH-P,PC2R-P,PC2RH-P,PC2W-P,PC2WH-P,SPWW-P,

SPSR-P,SPSWH-P,SPSRH-P,SPSWV-P,SPSRV-P,SPSCW-P,SPSCWH-P,SPSCWV-P,

SPSCWVH-P.

Architectural/Engineering Specifications

The System Sensor SpectrAlert Advance color lens attachments shall be approved for fire protective service as listed in UL 1638. The lens attachments shall only be

used with non-fire printed System Sensor strobe devices. The lens shall mount to any wall or ceiling mount strobes and be rated from −35°F to 151°F.

Lens Installation

Installation to Wall Mount Strobe

Installation to Ceiling Mount Strobe

Candela Rating for UL1638

LightoutputofcolorlensesismeasuredperUL1638,onaxis,andisnot

derated.

Strobe Output (cd)

Candela

Switch Setting

On-Axis Candela Rating

(UL1638) – All Colors

15

15

15/75*

NA

30

30

75

75

95

95

110

110

115

115

135

135

150

150

177

177

185

185

*15/75Candelasettingnottobeusedwithcolorlenses
