RECTIFIER SPECIALISTS

R

DC COMPONENTS CO., LTD.

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Dimensions in inches and (millimeters)

TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SCHOTTKY BARRIER DIODES

VOLTAGE RANGE - 20 to 40 Volts

CURRENT - 0.35 Ampere

FEATURES

MECHANICAL DATA

* For general purpose applications

* Low turn-on voltage

* Fast switching time

* Protected by a PN junction guard ring against excessive

voltage, such as electrostatic discharge(ESD)

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

Peak Forward Surge Current 8.3 ms single half sine-wave

superimposed on rated load (JEDEC Method)

Typical Thermal Resistance (Note1)

Typical Junction Capacitance (Note 2)

SYMBOL

UNITS

Volts

Volts

Volts

Amps

0.35

2.0

Amps

Storage Operating Temperature Range

R

-55 to + 125

pF

Maximum DC Reverse Current

µAmps

Maximum Instantaneous Forward Voltage

300

50

30

21

30

0.6

Volts

LL103A

LL103B

0.37

Note: 1. Terminals maintained at specified at ambient temperature.

2. Measured at 1 MHz and applied reverse voltage of 0 volts.

LL103C

LL103A

THRU

LL103C

40

28

40

20

14

20

* Case: Glass sealed case Mini Melf(DL-35)

* Terminals: Solder plated solderable per

MIL-STD-750, Method 2026

* Polarity: Color band denotes cathode end

* Mounting position: Any

* Weight: 0.05 gram approx.

Mini Melf(DL-35)

.016(0.4)

.008(0.2)

.059(1.5)

.055(1.4)

.142(3.6)

.134(3.4)

.016(0.4)

.008(0.2)

CATHODE MARK
