Elektronische Bauelemente

SCS4

448WS

Surface Mount Fast Switching Diode

ELECTRICAL CHARACTERISTICS (Ta=25

)

TYPE NUMBER

SYMBOL

Min.

Max.

UNITS

Test Condition

Reverse Breakdown Voltage

75

-

V

0.7

20

5.0mA

0.855

1.0

100mA

Forward Voltage (Note 2)

-

1.25

V

2.5

µA

25

25

Peak Reverse Current (Note 2)

-

25

nA

Total Capacitance

-

4.0

pF

Reverse Recovery Time

-

4.0

ns

NOTES:

1. Part mounted on FR-4 PC board with recommended pad layout,

2. Short duration test pulse used to minimize self-heating effect.

RATING AND CHARACTERISTIC CURVES
