PLA02A Characteristics

WWW.PHIHONG.COM

INPUT:

AC Input Voltage Range

Immunity

90 to 264VAC

EN61000-4-2, Level 3

AC Inrush Current

EN61000-4-5, Level 3

40A max @ 240VAC, 25°C

Input Power Saving

General

Leakage Current

<0.3W max @ 120/240VAC, no load

≤ 10 uA max

California Energy Commission Compliant,

Level IV

Dielectric Withstand (Hi-pot)

Efficiency

3KVAC, Primary to Secondary

MTBF (Full Load, 25°C)

≥ 56.23%

100K Hrs. min. at max load, 25°C ambient and

120VAC

OUTPUT:

Ripple (1)

DC Output Connector

250 mVp-p

2.1 mm x 5.5 mm Center Positive

AC Input Clip

Over Voltage Protection

5VDC: OVP shall not exceed 15V Max

Fixed US blade

9VDC: OVP shall not exceed 18V Max

12VDC: OVP shall not exceed 24V Max

Short Circuit Protection

Auto Recovery

ENVIRONMENTAL:

Operation Temperature (Convection)

0°C ~ 40°C

Storage Temperature

-40°C ~ 85°C

Humidity

90% RH Max

Emissions

FCC Class B

EN55022 class B

Note: (1) Measured after 10 minutes with by-pass

capacitors 0.1uf / 10uf at output connector terminal and

oscilloscope set at 20 MHz.

Phihong reserves the right to make changes without

further notice. Please consult Phihong USA and visit

www.phihong.com for the most up-to-date

specifications.

11-11-08
