(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Inductance code : R12 = 0.12uH

(a) Series code

2. CONFIGURATION & DIMENSIONS :

SUPERWORLD ELECTRONICS (S) PTE LTD

(d) Tolerance code : K = ±10%, M = ±20%

(e) F : Lead Free

SDI565047 SERIES

WIREWOUND CHIP INDUCTORS

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

31.07.2008

S D I 5 6 5 0 4 7 - R 1 2 M F

4. GENERAL SPECIFICATION :

c) Rated current : Base on temp. rise & L/L0A=10% Max.

b) Operating temp. : -25°C to 85°C

a) Ambient temp. : 20°C

2

3. SCHEMATIC :

1

B

A

5.7±0.3

5.0±0.3

A

E

CH

F

4.7±0.3

1.3 Min.

5.0 Ref.

1.7 Min.

J

I

2.0 Ref.

2.0 Ref.

Unit:m/m

F

B

E

I

I

J

PCB Pattern

E
