AC milliohmmeter checks Battery Condition in seconds

While the battery is in service

Battery Capacity Tester

Ordering Information:

BT100 ..........Battery Capacity Tester

BT102 ..........120V AC Adaptor

BT100-AL ....Replacement Alligator Clips for BT100

BT100-TL ....Replacement Test Leads for BT100

757057 ........Thermal Paper for PR20 (6pk)

USB100 ........RS-232 to USB Adaptor

Features:

and AC Milliohms

compatible software for downloading

readings to a PC

Specifications

Range

Resolution

Basic Accuracy

Resistance

40m

Ω, 400mΩ,

10μ

Ω, 100μΩ,

±(1% reading ± 8d)

4

Ω, 40Ω

1m

Ω, 10mΩ

Voltage

4V, 40V

1mV, 10mV

±(0.1% reading ±6d)

Max Input Voltage

50VDC

Power

6 AAA batteries

Battery life

7 hours

Dimensions

9.75 x 4 x 1.75" (250 x 100 x 45 mm)

Weight

17.5oz (500g)

Includes software with cable, Kelvin alligator clips,

Kelvin test leads, 6 AAA batteries
