Additional Documentation

Designers must have four documents to fully use all the

features of this device. This data sheet contains pin

descriptions, feature overviews, and electrical specifi-

cations. Errata sheets contain deviations from pub-

lished specifications. The user’s guides offer detailed

information about device features and operation. The

following documents can be downloaded from

www.maxim-ic.com/microcontrollers.

• This MAXQ2010 data sheet, which contains electri-

cal/timing specifications and pin descriptions.

• The MAXQ2010 revision-specific errata sheet

(www.maxim-ic.com/errata).

• The

MAXQ Family User's Guide, which contains detailed

information on core features and operation, including

programming (www.maxim-ic.com/MAXQUG).

• The

MAXQ Family User's Guide: MAXQ2010 Supplement,

which contains detailed information on features spe-

cific to the MAXQ2010.

Development and Technical

Support

Maxim and third-party suppliers provide a variety of

highly versatile, affordably priced development tools for

this microcontroller, including the following:

• Compilers

• In-circuit emulators

• Integrated Development Environments (IDEs)

• JTAG-to-serial converters for programming and

debugging

A partial list of development tool vendors can be found

at www.maxim-ic.com/MAXQ_tools.

For technical support, go to https://support.maxim-

ic.com/micro.

16-Bit Mixed-Signal Microcontroller

with LCD Interface

______________________________________________________________________________________

PACKAGE TYPE

PACKAGE CODE

DOCUMENT NO.

100 LQFP

—

21-0297

Package Information

For the latest package outline information and land patterns, go to www.maxim-ic.com/packages.

PART

PROGRAM

MEMORY (KB)

DATA MEMORY

(KB)

LCD SEGMENTS

ADC CHANNELS

ADC RESOLUTION

MAXQ2010-RFX+

160

Selector Guide
