1 / 1 page

TYPE CFSCP High reliability Series

CFSKB

CFSKP/CFSCP

CFSLP

CFSKP/CFSCP Dimensions

Taping data (CFSKP/CFSCP)

Marks

Dimensions

Marks

Dimensions

Marks

Dimensions

A1

9.0Max.

P2

6.35

± 1.3

H1

27.0Max.

T

4.0Max.

F1, F2

2.5 0.1

-

0.4

+

I

3.0Min.

d1

0.5

± 0.05

Δh

2.0Max.

øD0

4.0

± 0.2

d2

0.5

± 0.05

W

18.0 0.5

-

1.0

+

t2

1.5Min.

t0

0.3

± 0.05

W0

13.0 0.5

-

1.0

+

t1

0.6

± 0.3

P

12.7

± 1.0

W1

9.0

± 0.5

L

11.0Max.

P0

12.7

± 0.3

W2

1.0Max.

P1

3.85

± 0.5

H

18.0 0-2+

(Unit:mm)

Description

• Suitable for a radial taping. (CFSKP/CFSCP/CFSLP)

• The individual type for the CFSKP filter. (CFSKB)

概要

• ラジアルテーピング品（CFSKP/CFSCP/CFSLP）

• CFSKPタイプのバラ品対応（CFSKB）

Features

• Compact and low profile — ideal for slim-line sets.

• Low temperature coefficient with low spread for reliable

response.

• High selectivity for excellent spurious response control.

• RoHS compliant

特長

• 小型低背であり、薄形セットに最適

• 低温度係数で、バラツキが少なく安定した特性

• 高選択度特性で優れたスプリアス抑圧

• RoHS 指令対応

Applications

• Cordless telephones, audio systems, car stereo, high

grade radio cassettes.

• Digital communications equipment.

用途

• コードレス電話、ミニコンポ、カーステレオ、

高級ラジオカセット

• デジタル通信機器

SELECTION GUIDE FOR STANDARD FILTERS

TYPE CFSKP 10.7MHz

東光品番

中心周波数

3dB帯域幅

20dB帯域幅

挿入損失

スプリアス減衰量

入出力側

インピーダンス

TOKO

Part

Number

Center

Frequency

(MHz)

Bandwidth

at 3dB

(kHz)

Bandwidth

at 20dB

(kHz)Max.

Insertion

Loss

(dB)

Spurious

Response

(dB)Min.

Input/Output

Impedance

(

Ω)

#SKP107M1-A0-20

10.7

±0.03

280

±50

650

6.0

30

330/330

#SKP107M2-A0-20

10.7

±0.03

230

±50

600

6.0

40

330/330

#SKP107M3-A0-20

10.7

±0.03

180

±40

520

7.0

40

330/330

#SKP107M4-A0-20

10.7

±0.03

150

±40

400

10.0

40

330/330

TYPE CFSCP 10.7MHz

東光品番

中心周波数

3dB帯域幅

20dB帯域幅

挿入損失

スプリアス減衰量

入出力側

インピーダンス

TOKO

Part

Number

Center

Frequency

(MHz)

Bandwidth

at 3dB

(kHz)

Bandwidth

at 20dB

(kHz)Max.

Insertion

Loss

(dB)

Spurious

Response

(dB)Min.

Input/Output

Impedance

(

Ω)

#SCP107M2-A0-20C

10.7

±0.03

230

±50

520

3.0

±2.0

40

330/330

#SCP107M3-A0-20C

10.7

±0.03

180

±40

450

3.5

±1.5

40

330/330

#SCP107M4-A0-20C

10.7

±0.03

150

±40

340

4.5

±2.0

40

330/330

Radial Taping / FM Ceramic Filters

ラジアルテーピング／FMセラミックフィルタ

TYPE

CFSKP

CFSKB

CFSCP

CFSLP
