ADA4004-1/ADA4004-2/ADA4004-4

Rev. E | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V or +36 V

Input Voltage

Differential Input Voltage

±V supply

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

its exposed paddle soldered to a pad (if applicable) on a 4-layer

JEDEC standard printed circuit board with zero airflow.

Table 5.

Package Type

Unit

5-Lead SOT (RJ-5)

230

92

°C/W

8-Lead SOIC (R-8), ADA4004-1

177

53

°C/W

8-Lead SOIC (R-8), ADA4004-2

155

45

°C/W

8-Lead MSOP (RM-8)

186

52

°C/W

14-Lead SOIC_N (R-14)

115

36

°C/W

16-Lead LFCSP_VQ (CP-16-4)

44

31.5

°C/W

ESD CAUTION
