4 / 12 page

ADM6326/ADM6328/ADM6346/ADM6348

Rev. 0 | Page 4 of 12

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage, VCC

−0.3 V to +6 V

Input Current, ICC

20 mA

Output Voltage

Push-Pull RESET

−0.3 V to (VCC + 0.3 V)

Open-Drain RESET

−0.3 V to +6 V

Output Current (RESET)

20 mA

Rate of Rise of VCC

100 V/

μs

Temperature

Storage

−65°C to +155°C

Operating

−40°C to +85°C

Soldering (10 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type

θJA

Unit

3-Lead SOT-23

270

°C/W

ESD CAUTION
