LSRG2093-R17-AS-H-PF 데이터시트(PDF) 2 Page - LIGITEK electronics co., ltd. |
|
|
|||||||||||||||||||||||||||||
LSRG2093-R17-AS-H-PF 데이터시트(HTML) 2 Page - LIGITEK electronics co., ltd. |
|
|
2 / 7 page  1.CATHODE RED 2.COMMON ANODE 3.CATHODE GREEN Directivity Radiation Note : 1.All dimension are in millimeter tolerance is ±0.25mm unless otherwise noted. 2.Specifications are subject to change without notice. Package Dimensions PART NO. LSRG2093/R17-AS/H-PF Page 1/6 SR G 3 2 1 LIGITEK ELECTRONICS CO.,LTD. Property of Ligitek Only 4.2 6.7 ±0.5 5.2 2.0MIN 2.54TYP 2.0MIN 1 2 3 2.54TYP □0.5 TYP 1.5 MAX 18.0MIN 4.0 3.0 30 ° -60 ° 0 ° -30 ° -60 ° 75% 100% 25% 75% 100% 50% 25% 0 50% |
|
|
