T
T
TS
S
S---R
R
RD
D
DP
P
P7
7
7K
K
K///W
W
W
USB2.0 Portable Multi-Card Reader
Transcend Information, Inc.
3
USB Pinouts
Pin No.
Pin Name
01
V5IN
02
USB-
03
USB+
04
VSS
USB Pin Identification
Symbol
Function
USB-
USB+
USB differential signal:
The pairs are used to transmit
Data/Address/Command
VSS
Ground
V5IN
USB Power Input
Block Diagram
