Fiber Optic Receiver
MOF-R3K2
Fig. 1 Measuring Method of Optical Output Coupling with Fiber
Notes (1)Vcc=5.0V (State of operating)
(2)To bundle up the standard fiber optic cable, make it into a loop with the diameter D=10cm or more.
(3)Pc = -14.5 dBm
(4)Measured on an ammeter.
REV: A1
09/11/2001
Fiber optic cable
VOUT
VCC
A
MOF-R3K2
Standard transmitter
MOF-T3K2
VCC
5V
GND
Vin
Ammeter VCC
Input
GND
D
6 Mbps NRZ, Duty 50% or 3 Mbps biphase mark PRBS signal
Unity Opto Technology Co., Ltd.
3/4
