1 / 4 page  Input Characteristics 90-132/180-264Vac U = Autoranging Output Power/Current Vout ≥ 5V Vout < 5V S = 300W S = 60A P = 450W P = 90A M = 600W M = 120A Product Grade E = 0°C to +85°C Case C = 0°C to +85°C Case I = -30°C to +85°C Case Output Power/Current Vout ≥ 5V Vout < 5V Y = 50W Y = 10A X = 75W X = 15A W = 100W W = 20A V = 150W V = 30A U = 200W U = 40A Product Highlights If you’re looking for the convenience of a complete, low profile, agency- approved switching power supply, look no further. The FlatPAC combines Vicor’s workhorse VI-200 family of DC-DC converters with a modular package and front end subassembly to provide from 50 to 600W of output power from one to three outputs. A flat plate heatsink for use in conduction cooled applications may be specified as an alternate to the standard finned version by adding “CC” to the end of the model number. Vicor’s FlatPAC is also available with a current controlled output using BatMod converter modules of 12, 24, or 48Vdc outputs. This option is specified by appending “BM” or “BC” (for conduction cooled versions) to the end of the FlatPAC model number. The FlatPAC’s contemporary design allows us to configure your order quickly and provide rapid turnaround on standard models. It is truly a complete power solution, enabling you to spend more time designing your system and less time worrying about how to power it. Features ➤ Microcontroller architecture ➤ Inputs: 115/230Vac autoranging ➤ Meets FCC Part 15, EN55022, Class B conducted emissions ➤ 80-90% efficiency ➤ Any output: 1 to 95Vdc ➤ Module enable/disable (except LU series) ➤ UL, CSA, TÜV, VDE, BABT, CE marked ➤ Remote sense and current limit ➤ BUS OK and AC OK (except LU series) ➤ 40mS ride-through time ➤ OVP and thermal shutdown ➤ 1 output; up to 200W ➤ 1 or 2 outputs; up to 400W ➤ 1, 2, or 3 outputs; up to 600W FlatPAC ™ 50 to 600W Autoranging AC-DC Switchers FlatPAC Configuration Chart Typical Model: V I - R U – – Input: 115/230Vac; Output 1: 5Vdc at 200W Output 2: 12Vdc at 200W Output 3: 12Vdc at 200W # of Total Power Part No. Converters Dimensions 50-200W VI-LU – 1 9.25" x 2.5" x 1.37" (234,8 x 63,5 x 34,8mm) 200-400W VI-MU – 2 9.25" x 4.9" x 1.37" (234,8 x 124,5 x 34,8mm) 300-600W VI-NU – 3 9.25" x 7.3" x 1.37" (234,8 x 185,4 x 34,8mm) 100-400W VI-PU – 2 9.25" x 4.9" x 1.37" (234,8 x 124,5 x 34,8mm) 150-600W VI-QU – 3 9.25" x 7.3" x 1.37" (234,8 x 185,4 x 34,8mm) 150-600W VI-RU – 3 9.25" x 7.3" x 1.37" (234,8 x 185,4 x 34,8mm) U U U E 1 1 0 Single Outputs: Dual Outputs: Triple Outputs: Options BC = BatMod/Conduction Cooled BM= BatMod CC = Conduction Cooled Output Voltage Z 2V M 10V K 40V Y 3.3V 1 12V 4 48V 0 5V P 13.8V H 52V X 5.2V 2 15V F 72V W 5.5V N 18.5V D 85V V 5.8V 3 24V B 95V T 6.5V L 28V R 7.5V J 36V Output Power Vout ≥ 5V Vout < 5V W = 100W W = 20A V = 150W V = 30A U = 200W U = 40A S = 300W S = 60A Q = 400W Q = 80A FlatPAC 10/02 1 of 4 |
