How to Order





0.5W





1KR

RSS



RSS, RSN Metal Oxide Resistors

Back to 1st Page - Metal Oxide Resistors (RSS, RSN)



Part Number: RSS, RSN



Rated Power (W)



Resistance Value (Ω)



Resistance Tolerance (%)

Code

Resistance Tolerance

±5%



Package

Application Notes

Code

Resistance Value

10R

10Ω

100R

100Ω

1KΩ

10K

10KΩ

Code

Package

Taping Box

● Never use organic solvents to clean non-flammable resistors.

● Maintaining a surface temperature of 200°C or less will extend resistors service life.

● Although the hardness exceeds that of a 3H pencil lead, do not nick the coating with screwdrivers

or other pointed objects.

● Smoke emitted from non-flammable resistors on initial use in powered circuits is a normal

phenomenon and the component can be safely utilized.

● Non-flammable resistors cannot be utilized in oil. Non-flammable resistors cannot be used in high

frequency machinery because of the inductance produced by the grooving.

● Avoid touching non-flammable resistors in operation; the surface temperature ranges from

approximately 350 °C to 400°C when utilized at the full rated value.

● All metal oxide film resistors (RSS, RSN) manufactured by Token Electronics Co., Ltd. comply

with the U.S. UL-94 non-flammability test, Class V-0, a continuous combustion period of zero seconds.

● Less resistant against external shocks than ordinary resistors due to special flame retardant coating.

So, never give shocks or vibrations on the resistors. Also never damage them by picking up the

coated films with pliers, tweezers, etc.

● After cleaning, no external power should be put on the coated films before they are well dried.
