Now available from Token Electronics is a new range of highly stable and reliable metal oxide resistors

providing high power in a small package with various forming styles and different leads for different

applications.

New RS series resistors are ideal for pulse applications in adverse conditions and are available in different sizes

with power ratings of 0.5W to 10W for a power voltage range from 200V to 850V. Highly temperature resistant

the devices feature a resistance range from 10Ω to 47KΩ.

RS series resistors are available in various forming styles and different leads for different applications like power

supplies, amplifiers, household appliances and ballasts.

Manufactured by depositing a homogeneous oxide film of metal alloy onto a high-grade ceramic body, the metal

oxide resistors are coated with a nonflammable lacquer providing mechanical, electrical and climatic protection.

The devices come packaged in ammo pack boxed or tape and reel format. All RS Series devices are RoHS-

compliant, and compatible with high temperature soldering processes normally employed for lead free solders.

RSS, RSN Metal Oxide Resistors

Applications

- Ballasts

- Amplifiers

- Power supplies

- Telecommunications

- Household appliances

- Automotive, Computer, Instrumentation

Metal Oxide Resistors on The Pulse

in Various Forming Styles for Different Applications

Metal Oxide Resistors

Features

- Tolerances: G (±2%), J (±5%)

- Lead (Pb)-free and RoHS compliant

- Power wattages up to 10W at + 25 °C

- Operating temperature range: -55°C~200°C

- Axial leaded type, high power at compact sizes

- Replace carbon composition components in some applications
