ADL5535

Rev. 0 | Page 4 of 16

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

FREQUENCY = 900 MHz

Gain

15.1

vs. Frequency

±50 MHz

±0.11

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.20

vs. Supply Voltage

4.75 V to 5.25 V

±0.06

Output 1 dB Compression Point (P1dB)

19.0

dBm

Output Third-Order Intercept (OIP3)

Δf = 1 MHz, output power (POUT) = 3 dBm per tone

40.0

dBm

Second Harmonic

POUT = 0 dBm

−59.3

dBc

Third Harmonic

POUT = 0 dBm

−64.6

dBc

Noise Figure

3.2

FREQUENCY = 1000 MHz

Gain

14.9

vs. Frequency

±50 MHz

±0.11

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.21

vs. Supply Voltage

4.75 V to 5.25 V

±0.07

Output 1 dB Compression Point (P1dB)

18.9

dBm

Output Third-Order Intercept (OIP3)

Δf = 1 MHz, output power (POUT) = 3 dBm per tone

39.5

dBm

Second Harmonic

POUT = 0 dBm

−51.4

dBc

Third Harmonic

POUT = 0 dBm

−63.1

dBc

Noise Figure

3.3

POWER INTERFACE

Supply Voltage (VCC)

4.5

5.0

5.5

Supply Current

115

vs. Temperature

−40°C ≤ TA ≤ +85°C

±2.0

Power Dissipation

VCC = 5 V

0.5
