OSMH50830GP-R5MAS1C1A-D 데이터시트(PDF) 2 Page - OptoSupply International

부품명 OSMH50830GP-R5MAS1C1A-D
상세설명  White LED Ribbon Light
PDF  4 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  OPTOSUPPLY [OptoSupply International]
홈페이지  http://www.optosupply.com
Logo OPTOSUPPLY - OptoSupply International

OSMH50830GP-R5MAS1C1A-D 데이터시트(HTML) 2 Page - OptoSupply International

  OSMH50830GP-R5MAS1C1A-D Datasheet HTML 1Page - OptoSupply International OSMH50830GP-R5MAS1C1A-D Datasheet HTML 2Page - OptoSupply International OSMH50830GP-R5MAS1C1A-D Datasheet HTML 3Page - OptoSupply International OSMH50830GP-R5MAS1C1A-D Datasheet HTML 4Page - OptoSupply International
Zoom Inzoom in Zoom Outzoom out
 2 / 4 page
background image
2
Model No.
OSMH50830GP-
XXXXS1C1A-D
REV.
C3
Device Selection Guide
1
Module No.
Color
Dom. Wavelength
(Typ.)
Intensity / Per LED
(Typ.)
R5MAS1C1A -X
Red
625±5nm
1000 mcd
O5MAS1C1A -X
Orange
605±5nm
1000 mcd
Y5MAS1C1A -X
Yellow
590±5nm
1000 mcd
G5DAS1C1A -X
Green
530±5nm
900 mcd
B5SAS1C1A -X
Blue
475±5nm
400 mcd
W5SAS1C1A -X
White
X=0.27 ; Y=0.28
1500 mcd
M5SLS1C1A -X
Warm White
X=0.45 ; Y=0.41
1000 mcd
K5SLS1C1A -X
Pink
X=0.45 ; Y=0.17
300 mcd
Absolute Maximum Ratings(Ta=25℃)
1
Items
Symbol
Values
Units
Operating supply range(DC)
Vidc
14
V
Input Current (DC)
Ii
300
mA
Power Dissipation
Pa
4.2
W
LED Light Source Temperature
Tled
105
DegC
Operating Temperature
Tope
-10 ~ +40
DegC
Storage Temperature
Tsto
-20 ~ +80
DegC
Typical Performance (Ta=25℃)
1
Items
Symbol
Min.
Typ.
Max.
Units
LED Module Power
Pm
-
2.4
4.2
w
Input Voltage(DC)
Vi
-
12
14
V
Product input Current
If
-
200
300
mA
Beam Pattern
BP
-
120
-
Deg
Total Length of Modules
(Including Pin)
Lmod.
-
500
-
mm
Net Weight
Wei.
---
6
---
g



Html Pages
