4-74
RF2308
Rev B2 010228
4
Evaluation Board Schematic
(Download Bill of Materials from www.rfmd.com.)
Evaluation Board Layout
Uses same board as RF2306
1.27” x 1.02”
1
2
3
4
8
7
6
5
C2
100 pF
R1
27
Ω
C3
100 pF
C4
10 nF
L1
47 nH
C1
100 pF
SMA
J2
P1-3
RF OUT
(50
Ω)
SMA
J1
RF IN
(50
Ω)
NC
P1-3
P1
VCC
GND
1
2
3
2308400 Rev B
50
Ωµstrip
50
Ωµstrip
