Max. leakage current, line to ground:

Capacitor Identifier/Value

@ 120/VAC 60 Hz

@ 250 VAC 50 Hz

Blank / None

2

µA

5

µA

Q / 33pF

2.1

µA

3.65

µA

R / 100pF

9.6

µA

16.6

µA

S / 220pF

19.2

µA

33.2

µA

T / 330pF

24.0

µA

41.5

µA

W / 470pF

0.04mA

0.07mA

X / 1000pF

0.07mA

0.13mA

Rated current: 15A

Rated voltage (max.): 250 VAC

Operating frequency: 50/60 Hz

ELECTRICAL

Key Features

Unique Slide-In Mounting

Style

UL Recognized and CSA

Certified for 15 Amps at

250V

VDE Approved for 10

Amps at 250V

Unfiltered or Filtered

Compact Depth

X Version Available Now

Y Version – Coming Soon

DESCRIPTION

Tyco Electronics | CORCOM SRB Series

Power Line Filter with

Slide-in Mounting Style

The newest addition to the SRB series filter features a unique,

panel mounting option. This new ‘slide-in’ mounting approach

provides a simple, cost effective installation method, reducing

the need for additional mounting hardware. The slide-in

product offers two versions of the new mounting style with

either retention capability along the short edges of the filter

(X Style) or retention capability along the long edges of the

filter (Y Style).

CORCOM SRB Series

Power Line Filter with

Slide-in Mounting Style

MINIMUM INSERTION LOSS IN dB:

Line-to-ground in 50 ohm circuit

Frequency - MHz

Capacitor ID

1

5

10

50

100

300

Q

-

-

-

-

-

20

R

-

-

-

3

6

22

S

-

-

1

6

17

19

T

-

-

2

13

13

19

W

-

2

4

18

13

20

X

-

5

9

25

10

17

RoHS

Ready

Communications

Computer and Consumer Electronics

Industrial and Commercial

Instrumentation and Medical Equipment

APPLICATIONS
