74ACT715S-RSC 데이터시트(PDF) 12 Page - Fairchild Semiconductor

부품명 74ACT715S-RSC
상세설명  Programmable Video Sync Generator
PDF  18 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  FAIRCHILD [Fairchild Semiconductor]
홈페이지  http://www.fairchildsemi.com
Logo FAIRCHILD - Fairchild Semiconductor

74ACT715S-RSC 데이터시트(HTML) 12 Page - Fairchild Semiconductor

Back Button 74ACT715S-RSC Datasheet HTML 8Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 9Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 10Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 11Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 12Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 13Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 14Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 15Page - Fairchild Semiconductor 74ACT715S-RSC Datasheet HTML 16Page - Fairchild Semiconductor Next Button
Zoom Inzoom in Zoom Outzoom out
 12 / 18 page
background image
©1988 Fairchild Semiconductor Corporation
www.fairchildsemi.com
74ACT715, 74ACT715-R Rev. 1.3
12
RS170 Horizontal Data
RS170 Verticle Data
Signal
Width
µs
%H
Specification (µs)
HFP
22 Clocks
1.536
1.5 ± 0.1
HSYNC Width
68 Clocks
4.749
7.47
4.7 ± 0.1
HBLANK Width
156 Clocks
10.895
17.15
10.9 ± 0.2
HDRIVE Width
91 Clocks
6.356
10.00
0.1H ± 0.005H
HEQP Width
34 Clocks
2.375
3.74
2.3 ± 0.1
HSERR Width
68 Clocks
4.749
7.47
4.7 ± 0.1
HPER iod
910 Clocks
63.556
100
Signal
Width
µs
%H
Specification (µs)
VFP
3 Lines
190.67
6 EQP Pulses
VSYNC Width
3 Lines
190.67
6 Serration Pulses
VBLANK Width
20 Lines
1271.12
7.62
0.075V ± 0.005V
VDRIVE Width
11.0 Lines
699.12
4.20
0.04V ± 0.006V
VEQP Intrvl
9 Lines
3.63
9 Lines/Field
VPERiod (field)
262.5 Lines
16.683 ms
16.683ms/Field
VPERiod (frame)
525 Lines
33.367 ms
33.367ms/Frame
