BC461

Bipolar PNP Device.

V

60V

I

All Semelab hermetically sealed products

can be processed in accordance with the

requirements of BS, CECC and JAN,

JANTX, JANTXV and JANS specifications

Parameter

Test Conditions

Min.

Typ.

Max.

Units

V

60

V

I

C(CONT)

2

A

h

FE

@ 4/0.5 (V

40

250

-

f

t

50M

Hz

P

D

1

W

* Maximum Working Voltage

Semelab Plc reserves the right to change test conditions, parameter limits and package dimensions without notice. Information furnished by Semelab is believed

to be both accurate and reliable at the time of going to press. However Semelab assumes no responsibility for any errors or omissions discovered in its use.

Generated

1-Aug-02

Bipolar PNP Device in a

Hermetically sealed TO39

Metal Package.

Semelab plc.

Telephone +44(0)1455 556565. Fax +44(0)1455 552612.

Dimensions in mm (inches).

0.89

(0.035)

max.

12.70

(0.500)

min.

0.41 (0.016)

0.53 (0.021)

dia.

5.08 (0.200)

typ.

0.71 (0.028)

0.86 (0.034)

2.54

(0.100)

45°

6.10 (0.240)

6.60 (0.260)

8.51 (0.34)

9.40 (0.37)

7.75 (0.305)

8.51 (0.335)

1

2

3

0.74 (0.029)

1.14 (0.045)

TO39 (TO205AD)

PINOUTS

1 – Emitter

2 – Base

3 – Collector
