AD7466/AD7467/AD7468

Rev. C | Page 11 of 28

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted. Transient currents of up to

100 mA do not cause SCR latch-up.

Table 5.

Parameter

Rating

VDD to GND

−0.3 V to +7 V

Analog Input Voltage to GND

−0.3 V to VDD + 0.3 V

Digital Input Voltage to GND

−0.3 V to +7 V

Digital Output Voltage to GND

−0.3 V to VDD + 0.3 V

Input Current to any Pin Except Supplies

±10 mA

Operating Temperature Range

Commercial (B Version)

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

SOT-23 Package

θJA Thermal Impedance

229.6°C/W

θJC Thermal Impedance

91.99°C/W

MSOP Package

θJA Thermal Impedance

205.9°C/W

θJC Thermal Impedance

43.74°C/W

Lead Temperature, Soldering

Vapor Phase (60 sec)

215°C

Infrared (15 sec)

220°C

ESD

3.5 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
