Package pinouts and signal descriptions

MPC5602D Microcontroller Data Sheet, Rev. 3.1

Preliminary—Subject to Change Without Notice

Freescale Semiconductor

Package pinouts and signal descriptions

3.1

Package pinouts

The available LQFP pinouts are provided in the following figures. For pin signal descriptions, please refer to Table 3.

Reset generation module

(MC_RGM)

Centralizes reset sources and manages the device reset sequence of the device

Non-Maskable Interrupt (NMI)

Handles external events that must produce an immediate response, such as

power down detection

Periodic interrupt timer (PIT)

Produces periodic interrupts and triggers

Real-time counter (RTC)

Provides a free-running counter and interrupt generation capability that can be

used for timekeeping applications

System integration unit lite (SIUL) Provides control over all the electrical pad controls and up 32 ports with 16 bits

of bidirectional, general-purpose input and output signals and supports up to 32

external interrupts with trigger event configuration

Static random-access memory

(SRAM)

Provides storage for program code, constants, and variables

System status and configuration

module (SSCM)

Provides system configuration and status data (such as memory size and status,

device mode and security status), device identification data, debug status port

enable and selection, and bus and peripheral abort enable/disable

System timer module (STM)

Provides a set of output compare events to support AUTOSAR and operating

system tasks

System watchdog timer (SWT)

Provides protection from runaway code

Wakeup Unit (WKPU)

Supports up to 18 external sources that can generate interrupts or wakeup

events, of which 1 can cause non-maskable interrupt requests or wakeup events.

Table 2. MPC5602D series block summary (continued)

Block

Function
