UNISONIC TECHNOLOGIES CO., LTD

2N7002K

Preliminary

Power MOSFET

www.unisonic.com.tw

1 of 4

QW-R502-541.a

300m Amps, 60 Volts

N-CHANNEL ENHANCEMENT

MODE MOSFET

DESCRIPTION

The UTC 2N7002K uses advanced technology to provide

excellent RDS(ON), low gate charge and low gate voltages during

operation. This device is suitable for use as a load switch or in

PWM applications.

FEATURES

* Low Reverse Transfer Capacitance (CRSS = typical 3.0 pF)

* ESD Protected

* Fast Switching Capability

* Avalanche Energy Specified

* Improved dv/dt Capability, High Ruggedness

SYMBOL

2.Gate

1.Source

3.Drain

ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

123

45

6

Packing

2N7002KL-AE2-R

2N7002KG-AE2-R

SOT-23-3

S

G

D

-

Tape Reel

MARKING
