1 / 13 page

UNISONIC TECHNOLOGIES CO., LTD

88CXX

CMOS IC

www.unisonic.com.tw

1 of 13

QW-R502-040,E

BUILT-IN DELAY CIRCUIT

HIGH-PRECISION VOLTAGE

DETECTOR

DESCRIPTION

The UTC 88CXX series are highly accurate, low power

consumption voltage detector, manufactured using CMOS process.

The detection voltage is fixed internally, with an accuracy of ±2.0%.

Besides, UTC 88CXX can easily delay a release signal by

attachment of an external capacitor with built-in delay circuit.

FEATURES

* Highly accurate

: 2.0%

* Hysteresis characteristics: 5% typ.

* Ultra-low current consumption: 1.0μA typ. (VDD=2.0V)

* Detection voltage ranges: 1.5~6V and step by 0.1V.

* Low operating voltage based on detection voltage

* Delay time setting by an additional external capacitor.

SOT-25

1

3

5

2

4

ORDERING INFORMATION

Ordering Number

Normal

Lead Free

Halogen Free

Package

Packing

88CXX-AF5-R

88CXXL-AF5-R

88CXXG-AF5-R

SOT-25

Tape Reel
