BA3308

Preliminary

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 4

www.unisonic.com.tw

QW-R107-015.Ba

TYPICAL APPLICATION CIRCUIT

+

-

ch1

123

4

5678

9

ALC

MUTE

ch2

+

-

C3

100μF

R3

39Ω

R5

18kΩ

R1

3.9KΩ

C1

10μF

+

+

+

C5

10μF

R7

1MΩ

++

C7

22μF

C8

330μF

C6

10μF

+

C2

10μF

++

C4

100μF

R4

39Ω

R2

3.9kΩ

R6

18kΩ

R8

220Ω

Vcc

7V

INPUT1

INPUT2

OUTPUT1

OUTPUT2

R9 (R10)

120kΩ

C9 (C10)

0.027μF

4.3kΩ

R11(R12)

the following NAB time constant circuit

between pins 1 and 3 and 7 and 9.
