BB178

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 2

www.unisonic.com.tw

QW-R601-032.a

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Continuous Reverse Voltage

32

V

Peak Reverse Voltage

In series with a 10 kΩ resistor

35

V

Continuous Forward Current

20

mA

Storage Temperature

-40~+150

°C

Operating Junction Temperature

-40~+125

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

10

nA

Reverse Current

200

nA

Diode Series Resistance

0.65

0.8

Ω

34.65

42.35 pF

Diode Capacitance

2.361

2.754 pF

Capacitance Ratio

d(2V)

d(1V)

C

C

f = 1 MHz

1.3

Capacitance Ratio

d(28V)

d(1V)

C

C

f = 1 MHz

13.5

Capacitance Ratio

d(28V)

d(25V)

C

C

f = 1 MHz

1.08

Capacitance Matching

d

d

C

ΔC

15 diodes (gliding)

2

%
