KA22241
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
5 of 6
www.unisonic.com.tw
QW-R110-001,C
TYPICAL APPLICATION CIRCUIT
1
2
3
4
5
6
7
8
9
ALC
channel 1
channel 2
mute
R1
15k
220
R1
15k
Vcc=7V
Note: On playback, connect the time constant circuit as follows below, instead of R1 of PINS 1, 3, 7, 9, which are
used in the NAB.
