background image
LCD Switches
Programmable OLED Video Switch and Display
IS Series
sales@greatecs.com
www.greatecs.com
4
SMARTSWITCH PART NUMBER & DESCRIPTION
SMARTSWITCH LCD SPECFICATIONS
Characteristics of Display
Display Device
Color OLED display module
Display Mode
Passive matrix
Viewing Area
12.9mm x 9.9mm (horizontal x vertical)
Pixel Format
52RGB x 36 pixels (horizontal x vertical)
Pixel Size
0.21mm x 0.22mm (horizontal x vertical)
Interface
Serial (SPI) interface
Number of Colors
65,536 Colors (16bit: B 5bit/G 6bit/R 5bit)
or 256 Colors (8bit: B 3bit/G 3bit/R 2bit)
Operating Temperature Range
–20°C ~ +70°C (–4°F ~ +158°F)
Storage Temperature Range
–30°C ~ +80°C (–22°F ~ +176°F)
Operating Life Time (Display)
15,000 hours (40% pixels ON)
Absolute Maximum Ratings
Items
Symbols
Ratings
Supply Voltage for
Logic/Interface
VDD
–0.3V to +4.0V
Supply Voltage for Drive
VCC
0.3V to +19.0V
Input Voltage
VI
–0.3V to V DD +0.3V
Current Consumption
(Temperature at 25°C, V DD = 2.8V, V CC = 16.0V)
Items
Symbols Min Typical
Max
All-Pixels-On Mode
*Drive System Power Current
ICC1
––
3.5mA
4.5mA
All-Pixels-On Mode
*Logic/IF System Power Current
IDD1
–– 0.16mA 0.2mA
Sleep Mode
**Drive System Power Current
ICC2
––
––
10A
Sleep Mode
**Logic/IF System Power Current
IDD2
––
––
10A
*All pixels shall be turned on with the maximum level gray scale
**All pixels shall be turned o (while chip is operating)
Optical Characteristics (Temperature at 25°C, Initial Value: 87 x 0F)
Items
Min
Typical
Max
Unit
Remarks
Luminosity
75
100
125
cd/m 2
White
(All pixels on)
White Color
Coordinate
(x)
0.29
0.31
0.35
––
(y)
0.30
0.35
0.40
––
Red Color
Coordinate
(x)
0.60
0.64
0.68
––
(y)
0.31
0.35
0.39
––
Green Color
Coordinate
(x)
0.26
0.30
0.34
––
(y)
0.59
0.63
0.67
––
Blue Color
Coordinate
(x)
0.10
0.14
0.18
––
(y)
0.12
0.18
0.24
––
Contrast Ratio
100
––
––
––
Part Number
Display Description
OLED
Pixel Format
ISC01P
Straight PC Terminals
Color OLED
Display Module
65,536 Colors
52RGB x 36 Pixels
Horizontal x Vertical
Absolute Maximum Ratings
Items
Symbols Minimum
Typical
Maximum
Supply Voltage for
Logic/Interface
VDD
2.4V
2.8V
3.5V
Supply Voltage for Drive
VCC
15.0V
16.0V
17.0V
Input High Level Voltage
VIH
0.8 x V DD
––
––
Input Low Level Voltage
VIL
––
––
0.2V x V DD
