PRELIMINARY

TECHNICAL DATA SHEET

6 Lake Street, Lawrence, MA 01841

Gort Road Business Park, Ennis, Co. Clare, Ireland

1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803

Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298

Website: http://www.microsemi.com

T4-LDS-0109 Rev. 1 (091991)

Page 3 of 4

NOTES:

Dimensions

1. Dimensions are in inches.

Symbol

Inches

Millimeters

2. Millimeters are given for general information only.

Min

Max

Min

Max

3. In accordance with ASME Y14.5M, diameters are equivalent to Φx

BL

0.215

0.225

5.46

5.72

symbology.

BW

0.145

0.155

3.68

3.94

CH

0.049

0.075

1.24

1.91

LH

-

0.020

-

0.508

0.085

0.125

2.16

3.17

0.045

0.075

1.14

1.90

0.070

0.095

1.78

2.41

0.035

0.048

0.889

1.21

0.135

0.145

3.43

3.68

0.047

0.057

1.19

1.45

0.030

0.070

0.762

1.78

0.020

0.035

0.508

0.88

TERM 1

Cathode

TERM 2

Anode 1

TERM 3

Anode 2

* FIGURE 2 - Physical dimensions and configuration (U4).
