a division of CUI INC

date

page

SERIES:

DESCRIPTION:

03/2011

1 of 5

LED DRIVER

VLED15

phone 503.612.2300

fax 503.612.2382 www.v-infinity.com

MODEL

output current

ouput power

input voltage

min.

(V dc)

max.

(V dc)

max.

(mA)

max.

(W)

nominal load

(V ac)

VLED15-120-350

24

48

350

16.8

115

VLED15-120-480

10

13.5

480

6.5

115

VLED15-120-600

8

12

600

7.2

115

VLED15-120-700

16

24

700

16.8

115

VLED15-120-800

8

12

800

9.6

115

VLED15-120-900

10

16

900

14.4

115

VLED15-120-900L

8

12

900

10.8

115

VLED15-120-1000

10

16

1,000

16

115

VLED15-120-1200

10

14.1

1,200

16.92

115

VLED15-120-1250

8

12

1,250

15

115

8

11.5

1,400

16.1

115

VLED15-120-1500

5

10

1,500

15

115

VLED15-230-350

24

48

350

16.8

230

VLED15-230-480

10

13.5

480

6.5

230

VLED15-230-600

8

12

600

7.2

230

VLED15-230-700

16

24

700

16.8

230

VLED15-230-800

8

12

800

9.6

230

VLED15-230-900

10

16

900

14.4

230

VLED15-230-900L

8

12

900

10.8

230

VLED15-230-1000

10

16

1,000

16

230

VLED15-230-1200

10

14.1

1,200

16.92

230

VLED15-230-1250

8

12

1,250

15

230

8

11.5

1,400

16.1

230

VLED15-230-1500

5

10

1,500

15

230

RoHS

FEATURES

•constant current

•high efficiency

•120 and 230 V ac inputs available

•0.35 ~ 1.5 A output current

•operates with industry standard dimmers

•compact encapsulated assembly

•active power factor correction

•over voltage, over current, over temperature,

short circuit protection: auto recovery

•high temperature operation (up to 90°C case)

•UL approved, ENEC approved, CE Mark

•long life > 50,000 hours

notes:

1. total LED forward voltage must be within these ratings under all conditions including dimming

2. 80°C maximum case rating
