LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R105-012,F

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

V+

15V /

±7.5V

V

Differential Input Voltage

15

V

Input Voltage

-0.3 ~ +15

V

Power Dissipation

300

mW

Junction Temperature

+125

°C

Operating Temperature

-20~+85

°C

Storage Temperature

-40~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Input Offset Voltage

2

5

mV

Input Offset Current

5

100

nA

Input Bias Current

100

500

nA

Large Signal Voltage Gain

88

100

dB

Input Common Voltage Range

V

V

Maximum Output Voltage Swing 1

3.5

V

Maximum Output Voltage Swing 2

3.2

V

Common Mode Rejection Ratio

CMR

80

90

dB

Supply Voltage Rejection Ratio

SVR

80

90

dB

Operating Current

3

4

5

mA

Slew Rate

SR

1.0

V/μs

Unity Gain Bandwidth

GB

1.3

MHz

Operating Voltage Range

V

+

15

V
