background image
STLDC08
Electrical characteristics
Doc ID 18476 Rev 1
9/29
Symbol
Parameter
Test conditions
Min.
Typ.
Max.
Unit
SENSE
VSENSE MAX
Maximum current sense
threshold
70
100
130
mV
ISENSE
Bias current
VSENSE = 20 V
10
20
µA
EN/PWM section
VIL
Low level threshold
VCC = 0.8 V
0.3
V
VIL
Low level threshold
VCC = 3.6 V
0.4
V
VIH
High level threshold
VCC = 0.8 V
0.8
V
VIH
High level threshold
VCC = 3.6 V
1.2
V
IEN/PWM
EN/PWM pin current
EN/PWM = 3.6 V
2
µA
IEN/PWM
EN/PWM pin current
EN/PWM = 5 V
5
µA
+ 5 V regulator
V5
Output voltage
VOUT = 6 V; I5 = 10 mA
4.8
5
5.2
V
ΔV5/ΔV
OUT
Line regulation
6 V < VOUT < 18 V; I5 = 10 mA
0.02
%/V
ΔV5
Load regulation
0 < I5 < 10 mA VOUT = 18 V
0.02
0.01
%/mA
VDROPOUT Dropout voltage
I5 = 10 mA
20
mV
ICC
Short circuit current
VOUT = 18 V; V5 = 0 V
140
mA
Table 7.
Electrical characteristics (continued)
