background image
INCHANGE Semiconductor
isc Product Specification
isc Silicon NPN Power Transistor
2SC2242
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC= 5mA; IB= 0
B
300
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= 100mA; IB= 10mA
3.0
V
VBE(on)
Base-Emitter On Voltage
IC= 50mA ; VCE= 10V
0.9
V
ICBO
Collector Cutoff Current
VCB= 240V; IE=0
1.0
μA
IEBO
Emitter Cutoff Current
VEB= 5V; IC=0
1.0
μA
hFE
DC Current Gain
IC= 50mA ; VCE= 10V
40
170
COB
Output Capacitance
IE= 0 ; VCB= 50V; ftest=1MHz
5.5
12
pF
fT
Current-Gain—Bandwidth Product
IC= 20mA ; VCE= 50V
20
50
MHz
isc Website：www.iscsemi.cn
