Thick Film Hybrid IC

INCHANGE

STK73902

Self-excitation Type Feedback Control

Switching Regulator

Features

Package Dimensions

﹒Power MOSFET devices

unit:mm

﹒Feedback control for high output voltage precision

﹒Driver circuit on-chip

﹒Overcurrent protection circuit on-chip

﹒Pin compatible with all other devices in the same

series of devices with 110 to 280W power ratings

﹒Higher oscillator frequency allows the use of

smaller pulse transformers

Applications

﹒CRT/CTV power supplies

﹒Office automation equipment power supplies

Block Diagram

Pin Functions

(1)

Amplifier circuit control

(2)

Ground

(3)

TR1 gate

(4)

Drive voltage input

(5)

Starting voltage input

(6)

OCP setting level input

(7) OCP input-voltage dependency

detection input

(8)

TR1 source

(9)

TR1 source

(11)

TR1 drain

(12)

TR1 drain
