NXP Semiconductors

SSL21081T/2T/3T/4T

GreenChip drivers for LED lighting

5.

Ordering information

5.1 Ordering options

Remark: All voltages unless otherwise specified are in V (AC).

[1]

The SO12 package variants have more so called fused leads than the SO8 variants and can be used when

higher output power is required.

current on pin DRAIN

SSL21083T,

SSL21084T

1

-

1

A

SSL21081T,

SSL21082T

2

-

2

A

voltage on pin DRAIN

SSL21083T,

SSL21084T

-

-

600

V

SSL21081T,

SSL21082T

-

-

300

V

high on-time

-

-

17.5

s

Table 1.

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Table 2.

Ordering information

Type number

Package

Name

Description

Version

SSL21081T

SSL21083T

SO8

plastic small package outline body; 8 leads; body width

3.9 mm

SOT96-1

SSL21082T

SSL21084T

SO12

plastic small package outline body; 12 leads; body width

3.9 mm

SOT1196-1

Table 3.

Ordering options

SSL2108X

platform variants

Input voltage

Internal MOSFET

characteristics

Package

Brownout

protection

selectable

SSL21081T

100 V; 120 V

300 V; 2



SO8

no

SSL21082T

100 V; 120 V

300 V; 2



SO12

yes

SSL21083T

100 V; 120 V;

230 V

600 V; 5



SO8

no

SSL21084T

100 V; 120 V;

230 V

600 V; 5



SO12

yes
