SSL21081T_2T_3T_4T

All information provided in this document is subject to legal disclaimers.

© NXP B.V. 2011. All rights reserved.

Preliminary data sheet

Rev. 2 — 6 December 2011

11 of 24

NXP Semiconductors

SSL21081T/2T/3T/4T

GreenChip drivers for LED lighting

9.

Limiting values

[1]

Human body model: equivalent to discharging a 100 pF capacitor through a 1.5 k

 series resistor.

[2]

Charged device model: equivalent to charging the IC up to 1 kV and the subsequent discharging of each

pin down to 0 V over a 1

 resistor.

[3]

An internal clamp sets the supply voltage and current limits.

Table 5.

Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol

Parameter

Conditions

Min

Max

Unit

General

SR

slew rate

on pin DRAIN

5

+5

V/ns

conversion frequency

25

200

kHz

total power dissipation

SO8 package

-

0.6

W

SO12 package

-

1

W

ambient temperature

40

+125

C

junction temperature

40

+150

C

storage temperature

55

+150

C

Voltages

supply voltage

continuous [3]

0.4

+14

V

voltage on pin DRAIN

600 V version

0.4

+600

V

300 V version

0.4

+300

V

voltage on pin HV

current limited

0.4

+600

V

voltage on pin SENSE

current limited

0.4

+5.2

V

voltage on pin NTC

current limited

0.4

+5.2

V

voltage on pin TONMAX

current limited

0.4

+5.2

V

Currents

supply current

at pin VCC [3]

-

20

mA

current on pin DRAIN

600 V version

1

1

A

300 V version

2

2

A

current on pin SOURCE

600 V version

1

1

A

300 V version

2

2

A

current on pin DVDT

-

1.3

A

electrostatic discharge

voltage

human body

model; (for all pins

except DRAIN and

HV)

[1]

2.0

+2.0

KV

human body

model for DRAIN

and HV

-1.0

+1.0

KV

charged device

[2]

500

+500

V
