Block diagram and pin description

LIS332AX

4/14

Doc ID 16932 Rev 1

Table 2.

Pin description

Pin #

Pin name

Function

1

NC

Internally not connected

2

res

Connect to Vdd

3

NC

Not connected

4

ST

Self-test (logic 0: normal mode; logic 1: self-test mode)

5

PD

Power-down (logic 0: normal mode; logic 1: power-down mode)

6

GND

0 V supply

7

NC

Not connected

8

NC

Not connected

9

Voutz

Output voltage Z channel

10

NC

Not connected

11

Vouty

Output voltage Y channel

12

NC

Not connected

13

Voutx

Output voltage X channel

14

NC

Not connected

15

res

Connect to Vdd

16

Vdd

Power supply
