Actual Size (Max.)

SERIES

LP4040R

LP5035R

LP5050R

LP5064R

Commercial Low Profile

Surface Mount Power Inductors

Physical Parameters

Inches

Millimeters

A

0.453 Max.

11.5 Max. (LP4040R)

0.539 Max.

13.7 Max.

B

0.406 Max.

10.3 Max. (LP4040R)

0.508 Max.

12.9 Max.

C

0.138 Max.

3.5 Max. (LP5035R)

0.157 Max.

4.0 Max. (LP4040R)

0.197 Max.

5.0 Max. (LP5050R)

0.252 Max.

6.4 Max. (LP5064R)

D

0.098 to 0.138

2.5 to 3.5 (LP4040R)

0.118 to 0.157

3.0 to 4.0

E

0.075 to 0.098

1.9 to 2.5 (LP4040R)

0.079 to 0.102

2.0 to 2.6

F

0.283 (Ref. only)

7.2 (Ref. only) (LP4040R)

Dimensions "A" and "C" are over terminals.

Operating Temperature Range -20°C to +125°C

Current Rating at 25°C Ambient 40°C Rise

Inductance Measured at 0.25 VAC with no DC Current

Incremental Current The current at which the

inductance will be decreased by a maximum of 20%

from its initial 0 DC value.

Application Frequency to 1.0 MHz

270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com

SERIES LP4040R

-R36M

-R45M

-R56M

-R88M

-1R0M

-1R5M

SERIES LP5035R

-R15M

-R22M

-R33M

-R47M

-R60M

-R68M

-R82M

-1R0M

-1R5M

SERIES LP5050R

-R22M

-R33M

-R47M

-R56M

-R68M

-R82M

-1R0M

-1R5M

-1R8M

SERIES LP5064R

-R22M

-R33M

-R47M

-R56M

-R68M

-R82M

-1R0M

-1R8M

-2R2M

60.0

45.0

40.0

38.0

36.0

33.0

75.0

65.0

62.0

55.0

51.0

49.0

44.0

40.0

35.0

110.0

80.0

65.0

55.0

54.0

53.0

50.0

48.0

40.0

112.0

65.0

63.0

62.0

60.0

50.0

49.0

41.0

40.0

30.0

29.0

25.0

20.0

18.0

16.0

41.0

39.0

37.0

32.0

29.0

28.0

25.0

24.0

19.0

51.0

42.0

38.0

36.0

34.0

31.0

29.0

23.0

19.0

53.0

46.0

41.0

37.0

35.0

33.0

32.0

24.0

22.0

1.20

1.50

1.80

3.00

3.30

4.20

1.20

1.30

1.50

2.00

2.20

2.50

3.00

3.50

5.50

0.800

1.10

1.30

1.50

1.70

2.30

2.50

4.10

4.90

0.700

0.900

1.20

1.40

1.60

1.90

2.00

3.20

4.20

0.36

0.45

0.56

0.88

1.0

1.5

0.150

0.220

0.330

0.470

0.600

0.680

0.820

1.00

1.50

0.220

0.330

0.470

0.560

0.680

0.820

1.00

1.50

1.80

0.220

0.330

0.470

0.560

0.680

0.820

1.00

1.80

2.20

For surface finish information, refer to www.delevanfinishes.com

LP4040R Packaging Tape & reel: 13" reel,

500 pieces max.

LP5035R Packaging Tape & reel: 13" reel,

500 pieces max.

LP5050R Packaging Tape & reel: 13" reel,

250 pieces max.

LP5064R Packaging Tape & reel: 13" reel,

250 pieces max.

Unique inductive coil construction presents two outer coils

ends, each integrally formed into a terminal lead at

opposed sides of the inductor.

1/2009
