LM4880

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 12

www.unisonic.com.tw

QW-R502-033,C

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

6.0

V

Input Voltage

V

ESD Susceptibility (Note 3)

ESD

3500

V

ESD Susceptibility (Note 4)

250

V

Power Dissipation (Note 5)

Internally limited

Junction Temperature

150

℃

Operating Temperature

-40 ~ +85

℃

Storage Temperature

-65 ~ +150

℃

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Absolute Maximum Ratings indicate limits beyond which damage may occur. Operating ratings indicate

conditions for which the device is functional, but do not guarantee specific performance limits. Electrical

Characteristics state DC and AC electrical specifications under particular test conditions which guarantee

specific performance limits. This assumes that the device is within the operating ratings. Specifications are

not guaranteed for parameters where no limit is given, however, the typical value is a good indication of

device performance.

3. Human body model, 100 pF discharged through a 1.5 kΩ resistor.

4. Machine model, 220 pF ~ 240 pF discharged through all pins.

15℃, and the typical junction-to-ambient thermal resistance is 170℃/W for SOP-8 package and 107℃/W

for DIP-8 package.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

DIP-8

107

℃

/W

HSOP-8

42.3

Junction to Case

DIP-8

37

℃

/W

HSOP-8

12

OPERATING RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

2.7 ~ 5.5

V

-40 ~ +85

℃
