background image
Similar to TO-39-3
Semiconductor Group
1
1998-05-11
Silicon Piezoresistive
Pressure Sensor
KPY 62-RK
KPY 66-RK
Features
• Low pressure and temperature hysteresis
• Fast response
• High sensitivity and linearity
• Fatigue free monocrystaline silicon diaphragm
giving high load cycle stability
• High long term stability
• Built in silicon temperature sensor
• Metal housing
Type and
Marking
Symbol
Pressure Range
Unit
Ordering Code
KPY 62 RK
P
0
… P
N
0
… 600
mbar
Q62705-K319
KPY 63 RK
0
… 1.6
bar
Q62705-K320
KPY 64 RK
0
… 4
Q62705-K321
KPY 65 RK
0
… 10
Q62705-K322
KPY 66 RK
0
… 25
Q62705-K292
Pin Configuration
1
Temp.- Sensor
(typ.
R
25 = 2 kΩ)
2
Not connected
3+
V
IN; Temperature sensor
4
− V
OUT
5
No pin
6
Shielding, to be connected
to +
V
IN
7
− V
IN
8+
V
OUT
