UNISONIC TECHNOLOGIES CO., LTD

SSM3K333R

Preliminary

Power MOSFET

www.unisonic.com.tw

1 of 3

QW-R502-736.a

6A, 30V N-CHANNEL

POWER MOSFET

DESCRIPTION

The UTC SSM3K333R is an N-channel power MOSFET using

UTC’s advanced technology to provide customers with a minimum

on-state resistance and superior switching performance.

The UTC SSM3K333R is usually used in power management

switching applications.

FEATURES

* RDS(ON)<42mΩ @ VGS=4.5V

RDS(ON)<28mΩ @ VGS=10V

* High switching speed

* Low gate charge (Typ.=3.4nC)

* Low CRSS (Typ.=28pF)

SYMBOL

2.Gate

1.Source

3. Drain

ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

3

SSM3K333RL-AE3-R

SSM3K333RG-AE3-R

SOT-23

S

G

D

Tape Reel

Note: Pin Assignment: G: Gate

D: Drain

S: Source

MARKING
