background image
U74LVC2G07
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
3 of 5
www.unisonic.com.tw
QW-R502-402.A
ABSOLUTE MAXIMUM RATING (unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VCC
-0.5~6.5
V
Input Voltage
VIN
-0.5~6.5
V
Output Voltage(Active Mode)
VOUT
-0.5~6.5
V
Output Voltage(Power-Down Mode)
VOUT
-0.5~6.5
V
Input Clamp Current(VIN<0)
IIK
-50
mA
Output Clamp Current(VOUT<0)
IOK
-50
mA
Output Current
IOUT
±50
mA
VCC or GND Current
ICC
±100
mA
Operating Ambient Temperature
TOPR
-40 ~ +125
℃
Storage Temperature
TSTG
-65 ~ +150
℃
1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
Note:
3. When VCC =0V(Power-Down Mode),the output voltage can be 5.5V in normal operation.
RECOMMENDED OPERATING CONDITIONS
PARAMETER
SYMBOL
MIN
TYP
MAX
UNIT
Supply Voltage
VCC
1.65
5.5
V
Input Voltage
VIN
0
5.5
V
Active Mode
0
Vcc
Output Voltage
Vcc=0V; Power-Down Mode
VOUT
0
5.5
V
STATIC CHARACTERISTICS (TOPR =-40℃ to +85℃)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VCC =1.65V~1.95V
0.65*VCC
VCC =2.3V~2.7V
1.7
VCC =3.0V~3.6V
2.0
High-Level Input Voltage
VIH
VCC =4.5V~5.5V
0.7* VCC
V
VCC =1.65V~1.95V
0.35* VCC
VCC =2.3V~2.7V
0.7
VCC =3.0V~3.6V
0.8
Low-Level Input Voltage
VIL
VCC =4.5V~5.5V
0.3* VCC
V
VCC =1.65V ~ 5.5V, IOL=100μA
0.1
VCC =1.65V, IOL=4mA
0.45
VCC =2.3V, IOL=8mA
0.3
VCC =2.7V, IOL=12mA
0.4
VCC =3.0V, IOL=24mA
0.55
Low-Level Output Voltage
VOL
VCC =4.5V, IOL=32mA
0.55
V
Input Leakage Current
II(LEAK)
VCC =1.65V ~ 5.5V, VIN=5.5V or 0
±0.1
±5
μA
Power OFF Leakage Current
IOFF
VCC =0V, VIN or Vo=5.5V
±0.1
±10
μA
Quiescent Supply Current
IQ
VCC =5.5V, VIN=VCC or GND, IOUT=0
0.1
10
μA
Additional Quiescent Supply
Current per pin
ΔIQ
VCC =2.3V ~ 5.5V, VIN=Vcc-0.6V, Io=0A
5
500
μA
Output OFF-state current
IOZ
VCC =5.5V, VIN=VIH or VIL
Vo = VCC or GND
±0.1
±10
μA
